MSI B650 GAMING PLUS WIFI DDR5 ATX

Name: MSI B650 GAMING PLUS WIFI DDR5 ATX
Brand: MSI

AMD B650 · ATX · 2× M.2

Sockel

AM5

Chipsatz

AMD B650

Formfaktor

ATX

Speicher

DDR5

Max. Speicher

256 GB

M.2-Slots

Top-Nachbarn nach Beziehung gruppiert — klicken zum Öffnen

Zeig auf ein Teil, um zu sehen, was es ist — Klick öffnet es

Quelle: OpenDB

26 weitere Angaben zeigen

PCIe slots 3: Gen 3.0 · Lanes 1 · Quantity 1
ECC support: Nein
Fan headers · Pump: 1
Fan headers · CPU fan: 1
Fan headers · Case fan: 4
Form factor: ATX
RGB headers · ARGB 5v: 2
RGB headers · RGB 12v: 2
USB headers · USB 2.0: 2
USB headers · USB 3.2 gen 1: 1
USB headers · USB 3.2 gen 2: 1
Raid support: Ja
Bios features · Flashback: Ja
Bios features · Clear cmos: Nein
Other headers · Com port: 1
Storage devices · SATA 6 gb s: 4
Back panel ports: DisplayPort, 2.5G LAN, USB 3.2 Gen 2 10Gbps (Type-A), USB 3.2 Gen 1 5Gbps (Type-A), Wi-Fi / Bluetooth, Audio connectors, Flash BIOS Button, HDMI™, USB 3.2 Gen 2 10Gbps (Type-A), USB 3.2 Gen 2x2 20Gbps (Type-C)
Onboard ethernet 1: 2.5 Gb/s · Realtek 8125BG
Power connectors · CPU power: 8-pin, 8-pin
Power connectors · Main power: 24-pin
Front panel headers · HDD led: Ja
Front panel headers · Power led: Ja
Front panel headers · Power button: Ja
Front panel headers · Reset button: Ja
Wireless networking: Wifi 6E
Back connect connectors: Nein
