ASUS · gpu

Asus DUAL GeForce RTX 3060 Ti 8GB GDDR6X White

8 GB VRAM · 200 W · CUDA

Chipset

GeForce RTX 3060 Ti GDDR6X

VRAM

8 GB GDDR6X

Boost clock

1.695 GHz

TDP

200 W

Length

230 mm

Interface

PCIe x16

Neighbourhood

Top neighbours grouped by relation — click to open

Asus DUAL GeForce RTX 3060 Ti 8GB GDDR6X White

Point at a part to see what it is — click to open it

Specifications

Catalog data

Source: OpenDB

TDP: 200 W
Color: WHITE
Length: 230 mm
Memory: 8 GB
Chipset: GeForce RTX 3060 Ti GDDR6X
Cooling: 2 Fans
Interface: PCIe x16
Core count: 4864
Memory type: GDDR6X
Video outputs · HDMI 2.1: 1
Video outputs · DisplayPort 1.4a: 3
Core base clock: 1410 MHz

Show 5 more specs

Core boost clock: 1695 MHz
Power connectors · PCIe 8 pin: 2
Total slot width: 2 mm
Chipset manufacturer: NVIDIA
Effective memory clock: 19000 MHz

Manufacturer data

Source: Icecat

Cuda: Yes
Hdcp: Yes
Depth: 42 mm
Height: 120 mm
Length: 230 mm
Weight: 620 g
Cuda cores: 4864
Memory bus: 256 bit
Form factor: Full-Height/Full-Length (FH/FL)
Cooling type: Active
Hdcp version: 2.3
HDMI version: 2.1

Show 31 more specs

Nvidia ansel: Yes
Package type: Box
Dual link DVI: No
Nvidia g sync: Yes
Package depth: 220.5 mm
Package width: 368 mm
Interface type: PCI Express 4.0
Number of fans: 2 fan(s)
Opengl version: 4.6
Package height: 68 mm
Package weight: 1.1 kg
Product colour: White
Directx version: 12 Ultimate
Number of slots: 2
Cooling technology: ASUS Axial-tech
Data transfer rate: 19 Gbit/s
Graphics processor: GeForce RTX 3060 Ti
Maximum resolution: 7680 x 4320 pixels
DisplayPort version: 1.4a
HDMI ports quantity: 1
Tv tuner integrated: No
Displayports quantity: 3
Graphics card memory type: GDDR6X
Graphics processor family: NVIDIA
Minimum system power supply: 750 W
Processor boost clock speed: 1665 MHz
Discrete graphics card memory: 8 GB
Maximum displays per videocard: 4
Supplementary power connectors: 2x 8-pin
Processor boost clock speed (oc mode): 1695 MHz
Parallel processing technology support: Not supported

Gaming performance score

2500 / 10 000

Rank

#55

of 167 in our table

Estimated FPS at Medium preset with a Asus DUAL GeForce RTX 3060 Ti 8GB GDDR6X White and a Ryzen 5 7600.
Game	1080p	1440p	4K
Grand Theft Auto V	~300	~300	~240
Baldur's Gate III	~125	~70	~40
Red Dead Redemption 2	~80	~60	~25
Cyberpunk 2077	~65	~45	~20
Elden Ring	~100	~60	~35
Geometry Dash	≈300	≈300	≈300
Roblox	≈300	≈300	≈300
The Witcher 3: Wild Hunt	~165	~110	~75
Palworld	~60	~35	~20
Stardew Valley	≈300	≈300	≈300
Minecraft	~300	~300	~300
Clair Obscur: Expedition 33	~40	~30	~13
