Gigabyte · motherboard

Gigabyte B850 AI TOP AM5 DDR5 ATX

AMD B850 · ATX · 6× M.2

Socket

AM5

Chipset

AMD B850

Form factor

ATX

Memory

DDR5

Max memory

256 GB

M.2 slots

6

Neighbourhood

Top neighbours grouped by relation — click to open

Point at a part to see what it is — click to open it

Specifications

Catalog data

Source: OpenDB

Audio · Chipset: Realtek
Audio · Channels: 7.1
Color: BLACK
Memory · Max: 256 GB
Memory · Slots: 4
Memory · RAM type: DDR5
Socket: AM5
Chipset: AMD B850
M.2 slots 1: Key M · 2580-25110 · PCIe 4.0 x4
M.2 slots 2: Key M · 2280 · PCIe 4.0 x4
M.2 slots 3: Key M · 2580-25110 · PCIe 4.0 x4
M.2 slots 4: Key M · 2280 · PCIe 4.0 x4

Show 14 more specs

M.2 slots 5: Key M · 2580-25110 · PCIe 4.0 x4
M.2 slots 6: Key M · 2280 · PCIe 4.0 x4
PCIe slots 1: Gen 4.0 · Lanes 16 · Quantity 3
ECC support: No
Form factor: ATX
USB headers · USB 2.0: 2
USB headers · USB 3.2 gen 1: 1
USB headers · USB 3.2 gen 2x2: 1
Raid support: Yes
Bios features · Flashback: No
Bios features · Clear cmos: No
Back panel ports: 2 x 10 Gb/s Ports (Marvell AQtion AQC113C)
Onboard ethernet 1: 10 Gb/s · Marvell AQtion AQC113C
Back connect connectors: No
