Gigabyte · motherboard

Gigabyte Z790 AERO G DDR5 ATX

Name: Gigabyte Z790 AERO G DDR5 ATX
Brand: Gigabyte

Intel Z790 · ATX · 5× M.2

Socket

LGA 1700

Chipset

Intel Z790

Form factor

ATX

Memory

DDR5

Max memory

256 GB

M.2 slots

Top neighbours grouped by relation — click to open

Point at a part to see what it is — click to open it

Source: OpenDB

Show 31 more specs

M.2 slots 5: Key M · 2280 · PCIe 4.0 x4
PCIe slots 1: Gen 5.0 · Lanes 16 · Quantity 1
PCIe slots 2: Gen 4.0 · Lanes 4 · Quantity 1
PCIe slots 3: Gen 3.0 · Lanes 4 · Quantity 1
ECC support: Yes
Fan headers · Pump: 2
Fan headers · CPU fan: 1
Fan headers · CPU opt: 1
Fan headers · Case fan: 4
Form factor: ATX
RGB headers · ARGB 5v: 2
RGB headers · RGB 12v: 2
USB headers · USB 2.0: 2
USB headers · USB 3.2 gen 1: 1
USB headers · USB 3.2 gen 2x2: 1
Raid support: Yes
Bios features · Flashback: Yes
Bios features · Clear cmos: No
Other headers · Thunderbolt: 2
Other headers · Temperature sensor: 2
Storage devices · SATA 6 gb s: 4
Back panel ports: 1 x USB Type-C port (USB 3.2 Gen 2x2), 1 x USB Type-C port (USB 3.2 Gen 2, supports DisplayPort), 2 x USB 3.2 Gen 2 Type-A ports (red), 4 x USB 3.2 Gen 1 ports, 2 x USB 2.0/1.1 ports, 1 x DisplayPort In port, 1 x HDMI port, 1 x RJ-45 port (2.5GbE), 2 x SMA antenna connectors (2T2R), 2 x Audio jacks, 1 x Optical S/PDIF Out connector
Onboard ethernet 1: 2.5 Gb/s · Intel
Power connectors · CPU power: 8-pin, 4-pin
Power connectors · Main power: 24-pin
Front panel headers · HDD led: Yes
Front panel headers · Power led: Yes
Front panel headers · Power button: Yes
Front panel headers · Reset button: Yes
Wireless networking: Wifi 6E Bluetooth 5.3
Back connect connectors: No
