Sapphire · motherboard

SAPPHIRE NITRO+ B850A WIFI 7 AM5 DDR5 ATX

Name: SAPPHIRE NITRO+ B850A WIFI 7 AM5 DDR5 ATX
Brand: Sapphire

AMD B850 · ATX · 3× M.2

Socket

AM5

Chipset

AMD B850

Form factor

ATX

Memory

DDR5

Max memory

256 GB

M.2 slots

Top neighbours grouped by relation — click to open

Point at a part to see what it is — click to open it

Source: OpenDB

Show 27 more specs

PCIe slots 1: Gen 5.0 · Lanes 16 · Quantity 1
PCIe slots 2: Gen 4.0 · Lanes 4 · Quantity 1
PCIe slots 3: Gen 4.0 · Lanes 2 · Quantity 1
ECC support: No
Fan headers · Pump: 1
Fan headers · CPU fan: 1
Fan headers · Case fan: 3
Form factor: ATX
RGB headers · ARGB 5v: 3
RGB headers · RGB 12v: 1
USB headers · USB 2.0: 1
USB headers · USB 3.2 gen 1: 2
Raid support: No
Bios features · Flashback: Yes
Bios features · Clear cmos: No
Other headers · Com port: 1
Storage devices · SATA 6 gb s: 4
Back panel ports: 1 x DisplayPort, 1 x HDMI, 4 x USB 2.0, 3 x USB 3.2 Gen2 Type-A, 1 x USB 3.2 Gen2 Type-C, 1 x LAN (RJ45), 2 x Wi-Fi Antenna, 6 x Audio Jacks
Onboard ethernet 1: 2.5 Gb/s · Realtek RTL8125BG
Power connectors · CPU power: 8-pin, 8-pin
Power connectors · Main power: 24-pin
Front panel headers · HDD led: Yes
Front panel headers · Power led: Yes
Front panel headers · Power button: Yes
Front panel headers · Reset button: Yes
Wireless networking: Wifi 7
Back connect connectors: No
